Description
The 36V (18V X2) LXT® Brushless 9” Power Cutter Kit (XEC01PT1) has the power to cut through various materials with all the benefits and convenience of cordless operation. The XEC01PT1 has a maximum cutting depth of 3-1/2”, thus can cut through standard residential concrete slab in a single pass. Besides concrete, it has the power to cut through I-beams, steel pipe (3”), rebar (3/4” -#6), metal stud (14” wide) and more. The benefits of a cordless power cutter over a gas power cutter include no oil/gas mixing, no emissions, no pull starts, no engine maintenance, and lighter weight. This means reduced operator fatigue, instant starts, cost savings, and the ability to use the power cutter indoors, in tight spaces, and high elevations. An integrated water delivery system continuously feeds water for OSHA Table 1 Compliance in concrete cutting applications. Water flow is controlled with an adjustment knob. The belt-drive design provides smoother operation with lower vibration. The XEC01PT1 has a purpose-built BL™ Brushless Motor, which eliminates carbon brushes and enables the motor to run cooler and more efficiently for longer life. The brushless motor delivers 6,600 RPM. Active Feedback-sensing Technology (AFT®) turns the motor off if rotation of the wheel is suddenly forced to stop. An electric brake stops the wheel in 4 seconds or less allowing for faster re-positioning. And Makita's Extreme Protection Technology (XPT™) is designed to improve a tool’s operation in harsh conditions by channeling water and dust from key internal components. It’s part of Makita’s expanding 18V LXT System, the world’s largest cordless tool system powered by 18V lithium-ion slide-style batteries. Makita® 18V LXT Lithium-Ion Batteries have the fastest charge times in their categories, so they spend more time working and less time sitting on the charger.
Features
Eliminates the hassles of gas with lower weight, reduced maintenance, and zero emissions allowing use in indoor environments
Integrated water delivery system with water flow adjustment knob continuously feeds water for OSHA Table 1 Compliance in concrete cutting applications
Active Feedback-sensing Technology (AFT®) turns the motor off if rotation of the wheel is suddenly forced to stop
Electric brake stops the wheel in 4 seconds or less allowing for faster re-positioning
Built-in L.E.D. light with an independent on/off switch illuminates the cutting area for increased visibility
Makes single pass cuts up to a 3-1/2" depth in various masonry and metal materials
Integrated overload indicator alerts of excessive battery power draw during heavy loads
Overload protection is designed to protect the motor from burnout in abnormally high torque situations
Soft start suppresses start-up reaction for smoother start-ups and longer gear life
Protective battery compartment helps prevent dust and slurry contamination
Extreme Protection Technology (XPT™) is engineered for improved dust and water resistance for operation in harsh conditions
Rubberized front handle can be held in multiple positions for increased comfort at various cutting orientations
Belt-drive design provides smoother operation with lower vibration
Lock-off power switch requires two actions to start power
Large spindle lock button for easier wheel changes while wearing gloves
Lower noise at 114 dB(A) and smoother operation for continuous use over longer periods
Weighs only 13.7 lbs. with batteries for reduced operator fatigue
Integrated battery charge light indicator allows user to monitor battery charge level for each of the two batteries
Equipped with Star Protection Computer Controls™ to protect against overloading, over-discharging and over-heating
Compatible with Makita 18V Lithium-Ion batteries with a Star symbol
POWER - The BL™ Brushless Motor powered by two 18V LXT® batteries eliminate the hassle of engine pull starts
CAPACITY - Makes single pass cuts up to 3-1/2" in various materials
CONTROL - AFT® turns the motor off if rotation of the wheel is suddenly forced to stop
DUST MANAGEMENT - Integrated water delivery continuously feeds water for OSHA Table 1 Compliance
Includes
36V (18V X2) LXT® Brushless 9" Power Cutter (XEC01Z)
4 18V LXT® Lithium-Ion 5.0Ah Battery (BL1850B)
18V LXT® Lithium-Ion Dual Port Charger (DC18RD)
Water Hose Coupling (123120-4)
Universal Wrench, 13mm x 16mm (782023-7)
9" x .079" x 7/8" INOX Thin Cut-Off Wheel, 36 Grit (E-03012)
9" Diamond Blade, Segmented, General Purpose
Hex Wrench 4 (783202-0)
Battery: 2X 18V LXT® Lithium-Ion
No Load Speed: 6,600 RPM
Wheel Diameter: 9"
Max. Cutting Depth: 3-1/2"
Arbor Size: 7/8"
Lock-On Switch: No
Lock-Off Switch: Yes
Switch Type: Rear trigger switch
Electric Brake: Yes
Bind-Up Control: Yes
Overall Length: 21-3/4"
Net Weight (with battery): 13.7 lbs.
Power Type: Cordless
Shipping Weight: 28.67 lbs.
Motor Type: Brushless
Form Factor (LXT): X2
Country of Origin: Japan
Features
Eliminates the hassles of gas with lower weight, reduced maintenance, and zero emissions allowing use in indoor environments
Integrated water delivery system with water flow adjustment knob continuously feeds water for OSHA Table 1 Compliance in concrete cutting applications
Active Feedback-sensing Technology (AFT®) turns the motor off if rotation of the wheel is suddenly forced to stop
Electric brake stops the wheel in 4 seconds or less allowing for faster re-positioning
Built-in L.E.D. light with an independent on/off switch illuminates the cutting area for increased visibility
Makes single pass cuts up to a 3-1/2" depth in various masonry and metal materials
Integrated overload indicator alerts of excessive battery power draw during heavy loads
Overload protection is designed to protect the motor from burnout in abnormally high torque situations
Soft start suppresses start-up reaction for smoother start-ups and longer gear life
Protective battery compartment helps prevent dust and slurry contamination
Extreme Protection Technology (XPT™) is engineered for improved dust and water resistance for operation in harsh conditions
Rubberized front handle can be held in multiple positions for increased comfort at various cutting orientations
Belt-drive design provides smoother operation with lower vibration
Lock-off power switch requires two actions to start power
Large spindle lock button for easier wheel changes while wearing gloves
Lower noise at 114 dB(A) and smoother operation for continuous use over longer periods
Weighs only 13.7 lbs. with batteries for reduced operator fatigue
Integrated battery charge light indicator allows user to monitor battery charge level for each of the two batteries
Equipped with Star Protection Computer Controls™ to protect against overloading, over-discharging and over-heating
Compatible with Makita 18V Lithium-Ion batteries with a Star symbol
POWER - The BL™ Brushless Motor powered by two 18V LXT® batteries eliminate the hassle of engine pull starts
CAPACITY - Makes single pass cuts up to 3-1/2" in various materials
CONTROL - AFT® turns the motor off if rotation of the wheel is suddenly forced to stop
DUST MANAGEMENT - Integrated water delivery continuously feeds water for OSHA Table 1 Compliance
Includes
36V (18V X2) LXT® Brushless 9" Power Cutter (XEC01Z)
4 18V LXT® Lithium-Ion 5.0Ah Battery (BL1850B)
18V LXT® Lithium-Ion Dual Port Charger (DC18RD)
Water Hose Coupling (123120-4)
Universal Wrench, 13mm x 16mm (782023-7)
9" x .079" x 7/8" INOX Thin Cut-Off Wheel, 36 Grit (E-03012)
9" Diamond Blade, Segmented, General Purpose
Hex Wrench 4 (783202-0)
Specifications
Country of Origin: JapanBattery: 2X 18V LXT® Lithium-Ion
No Load Speed: 6,600 RPM
Wheel Diameter: 9"
Max. Cutting Depth: 3-1/2"
Arbor Size: 7/8"
Lock-On Switch: No
Lock-Off Switch: Yes
Switch Type: Rear trigger switch
Electric Brake: Yes
Bind-Up Control: Yes
Overall Length: 21-3/4"
Net Weight (with battery): 13.7 lbs.
Power Type: Cordless
Shipping Weight: 28.67 lbs.
Motor Type: Brushless
Form Factor (LXT): X2
Country of Origin: Japan
