Description
Base is drop-forged carbon steel and hot galvanized to ASTM A-153 to resist rust and corrosion.
U-bolts are colored blue for identification purposes and use heavy duty hex nuts (UNC-2A).
Designed to meet Federal specifications, FF-C-450, Type 1, Class 1 and designed to meet or exceed all requirements of ASME B30.26 including: identification, ductility, design factor and temperature. Permanently marked with size and manufacturer.
Minimum No. of Clips Required: 4
A Dimension: 5/8 in
B Dimension: 2-3/4 in
C Dimension: 1-1/2 in
D Dimension: 1-1/2 in
E Dimension: 1-1/2 in
F Dimension: 2-5/16 in
G Dimension: 2-5/16 in
H Dimension: 2-13/16 in
Weight Each (lbs.): 1.60 lb
Made in USA: Yes
U-bolts are colored blue for identification purposes and use heavy duty hex nuts (UNC-2A).
Designed to meet Federal specifications, FF-C-450, Type 1, Class 1 and designed to meet or exceed all requirements of ASME B30.26 including: identification, ductility, design factor and temperature. Permanently marked with size and manufacturer.
Specifications
For Rope Diameter: 3/4 inMinimum No. of Clips Required: 4
A Dimension: 5/8 in
B Dimension: 2-3/4 in
C Dimension: 1-1/2 in
D Dimension: 1-1/2 in
E Dimension: 1-1/2 in
F Dimension: 2-5/16 in
G Dimension: 2-5/16 in
H Dimension: 2-13/16 in
Weight Each (lbs.): 1.60 lb
Made in USA: Yes
