Description
Use this inverter to run your Milwaukee 120v charger in your car.
Continuous AC output power 150W
Peak AC output power 300W
AC output frequency 60 plusmn 3Hz
AC output waveform Modified sine wave
DC input voltage range 13.8 V DC, 12.5 A Max
Vehicle battery drain with no AC load (at 12V input) 0.33A
Efficiency (maximum) 80 Percent
Low vehicle battery shutdown point (nominal) 10.5V
High vehicle battery shutdown point (nominal) 15.5V
Replacement Fuse 10A
Max Operating Temperature 100 Degrees F (40 Degrees C)
120v Outlet 1
Specifications
AC output voltage (nominal) 120V AC/60HZ 150WContinuous AC output power 150W
Peak AC output power 300W
AC output frequency 60 plusmn 3Hz
AC output waveform Modified sine wave
DC input voltage range 13.8 V DC, 12.5 A Max
Vehicle battery drain with no AC load (at 12V input) 0.33A
Efficiency (maximum) 80 Percent
Low vehicle battery shutdown point (nominal) 10.5V
High vehicle battery shutdown point (nominal) 15.5V
Replacement Fuse 10A
Max Operating Temperature 100 Degrees F (40 Degrees C)
120v Outlet 1
