Description
The Makita 1-3/8" Magnetic Drill cuts holes in steel up to 1-3/8" diameter and 2" thick. The 10-amp motor delivers 850 RPM for enhanced cutting speed. The motor height adjusts for various cutting thickness. It weighs less so that the user can comfortably work in tight spaces or overhead, and for easy portability. The industrial chuck accepts 3/4" Weldon Shank Cutters. The drill features a magnetic base, which produces powerful clamping force for increased accuracy and stability while drilling, and a dovetail slide mechanism for smooth and consistent drilling performance. The removable guard isolates the cutting mechanism while rotating. A spindle coolant system with removable reservoir provides improved cutting performance. Removable feed handles allow for convenient storage.
Features
Cuts holes in steel up to 1-3/8" diameter and 2" thick
10 AMP motor delivers 850 RPM for enhanced cutting speed
Lightweight and portable design; ideal for working in constrained or elevated spaces
Removable guard isolates the cutting mechanism while rotating
Spindle coolant system with removable reservoir for improved cutting performance
Industrial chuck accepts 3/4" Weldon Shank cutters
Magnetic base produces powerful clamping force for increased accuracy and stability while drilling
Motor height adjusts for various cutting thickness up to 2"
Dovetail slide mechanism for smooth and consistent drilling performance
Simplified three button control panel for ease of operation
Removable feed handles for convenient storage
Integrated carrying handle for added convenience
Equipped with polyester strap for added support in horizontal or overhead applications
PERFORMANCE - Cuts holes in steel up to 1-3/8" diameter and 2" thick
POWER - 10 AMP motor delivers 850 RPM for enhanced cutting speed
PORTABILITY - Lightweight and portable design; ideal for working in constrained or elevated spaces
DESIGN - Removable guard isolates the cutting mechanism while rotating
INCLUDES - 500 mL coolant bottle, polyester safety strap, cutting guard, hex wrenches, and tool case
Includes
500 mL coolant bottle and connection hose
Polyester safety strap
Cutting guard
Hex wrenches
Tool case
AMPS: 10
No Load Speed (RPM): 850
Chuck Type: 3/4" Weldon
Capacity (cutting diameter): 1-3/8"
Cutting Capacity (depth): 2"
Length of Stroke: 6-19/64"
Overall Height: 19-5/16"
Overall Length: 8-7/8"
Net Weight: 26 lbs.
Shipping Weight: 37.49 lbs.
Country of Origin: United Kingdom
Features
Cuts holes in steel up to 1-3/8" diameter and 2" thick
10 AMP motor delivers 850 RPM for enhanced cutting speed
Lightweight and portable design; ideal for working in constrained or elevated spaces
Removable guard isolates the cutting mechanism while rotating
Spindle coolant system with removable reservoir for improved cutting performance
Industrial chuck accepts 3/4" Weldon Shank cutters
Magnetic base produces powerful clamping force for increased accuracy and stability while drilling
Motor height adjusts for various cutting thickness up to 2"
Dovetail slide mechanism for smooth and consistent drilling performance
Simplified three button control panel for ease of operation
Removable feed handles for convenient storage
Integrated carrying handle for added convenience
Equipped with polyester strap for added support in horizontal or overhead applications
PERFORMANCE - Cuts holes in steel up to 1-3/8" diameter and 2" thick
POWER - 10 AMP motor delivers 850 RPM for enhanced cutting speed
PORTABILITY - Lightweight and portable design; ideal for working in constrained or elevated spaces
DESIGN - Removable guard isolates the cutting mechanism while rotating
INCLUDES - 500 mL coolant bottle, polyester safety strap, cutting guard, hex wrenches, and tool case
Includes
500 mL coolant bottle and connection hose
Polyester safety strap
Cutting guard
Hex wrenches
Tool case
Specifications
Country of Origin: United KingdomAMPS: 10
No Load Speed (RPM): 850
Chuck Type: 3/4" Weldon
Capacity (cutting diameter): 1-3/8"
Cutting Capacity (depth): 2"
Length of Stroke: 6-19/64"
Overall Height: 19-5/16"
Overall Length: 8-7/8"
Net Weight: 26 lbs.
Shipping Weight: 37.49 lbs.
Country of Origin: United Kingdom
